Bluetooth Humidity & Temperature Logger (Android) with standard 4 point temperature and humidity calibration

The EL-BT-2 data logger measures and stores up to 500,000 temperature and humidity readings. The LCD screen on the device indicates Bluetooth connection status as well as logger operation. The push button allows cycling of current, minimum and maximum recorded values. The EL-BT-2 comes with rechargeable battery and can be used with a USB wall charger.

The EL-BT-2 is designed for use with Android tablets and smartphones only. The EasyLog BT app for Android is available on Google Play and allows you to manage your EL-BT-2 logger with ease.

Within the app you can set the sample rate, temperature scale, temperature and humidity alarms, Bluetooth power-save settings, LCD settings and variable start times. Downloaded data will be saved to your phone’s memory card and can be viewed at any time. You can then send the data via email or your preferred cloud service to another device or Windows PC for further analysis.

– Download recorded data and view on your device
– Animated walkthrough of the setup process
– Export the logger’s information via email or other cloud services

Specifications

– Measurement range (Temperature): -35 to +80 C (-31 to +176 F)
– Measurement range (Humidity): 0 to 100% RH- Resolution (Temperature): 0.1C (0.1F)- Resolution (Humidity): 0.1%- Accuracy (overall error*, temperature): 0.35 C (0.59 F) typical (5 to 60 C)- Accuracy (overall error*, humidity): 2.05 %RH typical (20 to 80%RH)- Long term stability (temperature): <0.02 C (0.04F)/year- Long term stability (humidity): <0.25%RH / year- Dew Point (Accuracy (overall error))*: 1.4 C typical (-35 to 80 C, 40 to 100%RH)- Operating temperature range: -20 to +60C (-4 to +140F)- Battery life: 6 months (at 25 C in power save mode)- Environmental protection: IP55- EasyLog BT app for Android: Version 4.0 (Ice Cream Sandwich) and later- Connection distance: Class 2 Radio 10m (30ft)* The overall error takes in to account the sensor accuracy and the resolution of the data logger. Please refer to the data sheet more information

Calibration:

– Calibrated at 35% and 75% rH at 20 C and 20 C + 40 C

Unboxing the IC-EL-BT-2 Bluetooth Humidity and Temperature Logger (Android):

How to Setup the IC-EL-BT-2 Bluetooth Humidity and Temperature Logger :
