MK350D Compact Spectrometer

Specifications

Spectrum:
– Sensor: CMOS Linear Image Sensor
– Wavelength Range: 380 to 780 nm- Wavelength Data Increment: 1 nm- Spectral Bandwidth: Approximately 12 nm (Half Bandwidth)- Wavelength Reproducibility: +/- 1 nm- Measurement Range: 70 to 70,000 lx- Stray light: -25 dB max.- Integration Time Range: 6 to 1,000 ms- Digital Resolution: 16 bits- Flicker: Frequency Range: 5 to 50 kHzMeasuring capabilities: – Illuminance (LUX)/Foot Candle (fc)
– Correlated Color Temperature (CCT)- CIE Chromaticity Coordinates- Color Rendering Index (CRI, Ra) / R9- Percent Flicker- Spectral Power Distribution (SPD)- Peak Wavelength System configurations: – Display: 0.96″ 128×64 mono OLED
– Max. files: 1.2 million Files at 8GB SD Card (Excel + JPG)- Battery Operation time: less than or equal to 4 hours / Fully Charged- Power: USB Power; 700 mA (3.7V Rechargeable Li-ion Battery)- Data Output Interface: Micro SD Card (SD2.0,SDHC/up to 32G)/Mini USB Port(USB 2.0)/Bluetooth 3.0 and 4.0 compatible with iOS and Android- Data Format: Compatible Excel – Dimensions: 90 x 30 x 32.2 mm?H x W x D?
