Multi Angle, Gloss Meter – Advanced Measurement

Our advanced function Gloss Meter allows users to measure and analyze the specular reflection (gloss level) on a wide range of materials at3 different incidence angles simultaneously (20/60/85 degrees).

Users select their required angle of incidence and upon pressing the measure key, a light beam is transmitted at the prescribed angle onto the test surface. This is reflected into the receiver sensor and a corresponding Gloss Unit (GU) value is displayed on screen in a matter of seconds.

The higher the GU value, the greater the glossiness is said to be.

The multi-angle Gloss Meter is commonly used for quality assessment. It is particularly useful to verify finishing polish on flooring products such as tiles, stone, pavers; also in the production of windows, various painted products in the printing and automotive industries.

Features:

– Large, backlit LCD
– Auto calibration (reference tile fitted into cradle)
– Data memory 250 readings
– Compact size for portability
– Rechargeable battery

Specifications

– Display: 4 digits, 10mm LCD
– Measuring Geometry: 20,60, 85 degrees
– Range: 0.1 to 200 GU
– Accuracy: +/- 1.0 GU
– Resolution: 0.1 GU
– Measuring Aperture: 7 x 14 mm
– Internal Memory: 250 readings
– Power Supply: Built-in rechargeable battery (USB charging)
– Dimensions: 140 x 45 x 75 mm
