Multiple Parameter Surface Roughness Meter

Our Starr Instruments RTD-200 Surface Roughness Tester is designed for users with a wide range of surface testing with detailed data analysis requirements.

It is commonly used to test in a work shop or laboratory to determine the roughness of surface finishes, both raw and machined. This is importantto measure quality and manage the manufacturing process. If a surface is too rough it can wear quickly with a higher co-efficient of friction. Converselyit can be expensive in the manufacturing process to make a surface smoother.

A good example is the maintenance of expensive molds used in the production of glass bottles. These need to be closely monitored to ensure a high quality,clear bottle is formed and is easily removed from the moulds after pouring. An Ra gauge can quickly determine if a mold needs to be refinished.

Designed with a protruding stylus, the RTD-200 is also suitable for curved surfaces. The bright OLED dot matrix screen is easy to read in daylightor low light and the ‘Dataview’ software makes managing data simple including graphing of results.

The RTD-200 uses a diamond tipped stylus to trace the surface of the material and through current induction transmits a signal that the device uses toproduce the measurements. The measurements are available in many profiles including Ra, Rz, Rq, Rp, Rv, R3z amongst others. The results are displayed onthe screen, save to memory and ouput to your PC for further detailed analysis and reporting.

Features:

– Easy to use
– Rugged metal body
– DSP chip for hi-speed data processing
– Large range of parameters
– OLED screen
– Data output and management
– Standard kit includes the main unit, stylus sensor, Ra sample, sample support, height support (adjustable), power adapter, USB cable and software.

Specifications

– Maximum Travel: 17.5mm
– Indicating Error: +/-10%
– Variation of Indication: +/- 6%
– Measured Profile: Roughness, Waviness, Contour
– Parameter: Ra (0.005 um-16 um) Rz (0.02 um-160 um)
– Parameter: Rq, Rt, Rp, Rv, R3z, R3y, RzJIS, Rsk, Rsu, Rsm,Rmr, Rx
– Filter: RC, PC-RC, Gauss, ISO13565
– Sampling Length “L”: 0.25mm, 0.8mm, 2.5mm, 8mm
– Evaluation Length: (1-5)L
– Interface: USB
– Power: Built in rechargeable battery
– Detection Principle: Current induction
– Stylus Force: 4mN (0.4gf)
– Stylus Angle: 90 degrees
– Calibration Template: included
